Brand: Celestron

Celestron C6 SCT (OTA) Optical Tube Assembly (CG-5 Dovetail) (91010-XLT)

91010-XLT

Brand: Celestron

Celestron C6 SCT (OTA) Optical Tube Assembly (CG-5 Dovetail) (91010-XLT)

91010-XLT

The Celestron C6-A OTA is a great multi-use optical tube with a 1500 mm focal length and a focal ratio of f/10. It offers 40% more light gathering than a 5" Cassegrain telescope.
  • 6" Schmidt-Cassegrain optical tube assembly (OTA)
  • Features Celestron's premium patented StarBright XLT optical coatings
  • 1500 mm focal length (f/10)
  • Tube constructed of durable and lightweight aluminum
Special Order
$839.95 USD

Easy Payment Options with .

How do I Special Order?
Special Order
$839.95 USD

Easy Payment Options with .

How do I Special Order?
Free Expert Support
Stress Free, Secure Shopping
30 Day Return Policy
Price Match Promise
Full Details What Can I See? What's in the Box? Specifications Reviews and Questions Articles, Videos, Software, Links

Product Description

The Celestron C6-A OTA is a great multi-use optical tube with a 1500 mm focal length and a focal ratio of f/10. It offers 40% more light gathering than a 5" Cassegrain telescope. The Celestron C6-A features Celestron's patented StarBright® XLT optical coatings, which visibly increase contrast and light transmission for brighter deep space images and shorter exposure times. With StarBright XLT, you'll be able to discern subtle details while viewing the Moon and planets as well as faint galaxies and nebulae.

The Celestron C6-A can be mounted on a multitude of computerized telescope mounts thanks to its CG-5 dovetail bar. But it also works well when mounted on a basic manual altazimuth mount for night sky viewing or as a terrestrial spotting scope during the day.

The Celestron C6-A has the best balance of portability, handling ease, light gathering ability and price ever offered to the amateur astronomer. It is an advanced level instrument that is as easy to use as any intermediate level-and most entry level-telescopes.

StarBright XLT coatings

StarBright XLT is Celestron's revolutionary optical coating system. It consistently outperforms all other coatings in the commercial telescope market. There are three major components that make up our StarBright XLT high-transmission optical system design:

  • Unique enhanced multi-layer mirror coatings made from precise layers of aluminum, SiO2 (quartz), TiO2 (titanium dioxide), and SiO2 (silicon dioxide). Reflectivity is fairly flat across the spectrum, optimizing it for both imaging and visual observing.
  • Multi-layer anti-reflective coatings made from precise layers of MgF2 (magnesium fluoride) and HfO2 (hafnium dioxide). Hafnium-a rare element that costs nearly $2,000 per kilogram-gives us a wider band pass than the titanium used in competing coatings.
  • High-transmission water white glass is used instead of soda lime glass for the corrector lens. Water white glass transmits about 90.5% of light without anti-reflective coatings; that's 3.5% better than uncoated soda lime glass. When water white glass is used in conjunction with StarBright XLT's anti-reflective coatings, the average transmission reaches an astonishing 97.4.

These three components make StarBright XLT one of the finest coatings available.

What can I see with a Celestron C6 SCT (OTA) Optical Tube Assembly (CG-5 Dovetail) (91010-XLT)?

Here are some simulated views of common objects. Results with your telescope will vary with viewing conditions, obrits, equipment and more.

Jupiter with

25mm Eyepiece - 60x Magnification

(Included with This Telescope)

Jupiter with

10mm Eyepiece - 150x Magnification

Sold Separately

Jupiter with

5mm Eyepiece - 300x Magnification

Sold Separately

Moon with 25mm Eyepiece

60x Magnification

(Included with This Telescope)

Moon with 10mm Eyepiece

150x Magnification

Sold Separately

Moon with 5mm Eyepiece

300x Magnification

Sold Separately

Andromeda with 36mm Eyepiece

42x Magnification

Sold Separately

Andromeda with 25mm Eyepiece

60x Magnification

(Included with This Telescope)

Andromeda with 10mm Eyepiece

150x Magnification

Sold Separately

What's in the Box

  • 6" Schmidt-Cassegrain optical tube assembly (OTA)
  • 25mm eyepiece (60x)
  • 6x30 optical finderscope
  • Star diagonal
  • 1.25" visual back
  • CG-5 dovetail bar

Specifications

Optical Design: Schmidt-Cassegrain
Aperture: 150mm (6")
Focal Length: 1500mm (59")
Focal Ratio: f/10
Focal Length of Eyepiece 1: 25mm (0.98")
Magnification of Eyepiece 1: 60x
Finderscope: 6x30
Star Diagonal: 1.25" Star Diagonal
Optical Tube: Aluminum
Highest Useful Magnification: 354x
Lowest Useful Magnification: 21x
Limiting Stellar Magnitude: 13.4
Resolution (Rayleigh): 0.93 arc seconds
Resolution (Dawes): 0.77 arc seconds
Light Gathering Power (Compared to human eye): 459x
Secondary Mirror Obstruction: 56mm (2.2")
Secondary Mirror Obstruction by Diameter: 37%
Secondary Mirror Obstruction by Area: 14%
Optical Coatings: StarBright XLT
Optical Tube Length: 406mm (16")
Optical Tube Diameter: 180mm (7.12")
Optical Tube Weight: 10 lbs (4.54 kg)
Dovetail: CG-5 Dovetail bar
