Brand: Sky-Watcher

SkyWatcher Wave 150i Strainwave Harmonic Drive Mount | S30905

S30905

Brand: Sky-Watcher

SkyWatcher Wave 150i Strainwave Harmonic Drive Mount | S30905

S30905

Sky-Watcher´s Wave mounts feature strainwave gearing that provides a lot of power in a little package. The strainwave configuration offers several advantages over traditional mount designs including low to zero backlash
and high torque.
  • Wave 150i GoTo strainwave head
  • EQ and AZ modes
  • Built-in cable management
  • Weighs 12.8 pounds (5.8kg)
  • 33-pound (10kg) payload capacity without optional counterweight
  • 55-pound (25kg) payload capaciy with optional counterweight
  • Single D/V hybrid saddle
  • Latitude range from 0° to 90°
  • Red LED for latitude scale and bubble level
  • Wi-Fi and Bluetooth
  • RA power off braking function
  • RA and DEC home position functions
  • Requires 12V 2A power (not included)
  • Optional tripod, pier extension, and counterweight kit not included
  • Optical Tube not included

This item is available for pre-order. General availability coming Summer 2024

$2,195.00 USD

Easy Payment Options with .

What is a Backorder?
$2,195.00 USD

Easy Payment Options with .

What is a Backorder?
Free Expert Support
Stress Free, Secure Shopping
30 Day Return Policy
Price Match Promise
Why We Love It Full Details What's in the Box? Specifications Reviews and Questions

Why we love the SkyWatcher Wave 150i Strainwave Harmonic Drive Mount | S30905

Sky-Watcher enters the field with their harmonic drive mount. A great entry with unique features backed by an industry giant.

Product Description

HIGH TORQUE. HIGH PRECISION. HIGH PORTABILITY.

Bringing Balance to the Force

Strainwave mounts are particularly suitable for serious astronomers and astrophotographers who require precise control over their telescope’s movements.

Weighing only 12.8 pounds and carrying a 33-pound payload (55lb. in EQ mode with the optional counterweight kit), With cable management built into the saddle, large payload capacity, and a small footprint, the Wave 150i is the ultimate portable imaging mount. Also featuring a whisper-quiet slew speed of 10 degrees per second, our new strainwave mounts can even track satellites and space stations.

Optional Accesories

The Wave series features a total line of accessories to complete your astronomical experience, including carbon fiber tripod, pier extension, and stainless steel counterweight kit.

What's in the Box

  • Mount Head Only

Specifications

General Mount Info
Mount Type Strainwave Harmonic Drive
Transmission Mode Stepper motor + belt drive and
harmonic reducer
Total Transmission Ratio 300:1
Payload Capacity With Out Counterweight  33 lbs
Payload Capacity with Counterweight 55 lbs
Mount Head Weight (lbs) 5.8kg 12.8 lbs
Max Slew Rate 2400x (10 degrees per second)
Latitude Range Continuously adjustable
from 0° to 90°
Mounting Saddle Type Single Hybrid Vixen/Losmandy
Power Type DC12V
Tracking Rates Sidereal, solar, Lunar
