Product Description
The AM5N - New and Improved for 2024!
- Load Enhancement: Maximum Load without a counterweight has increased all the way to 15kg (from the old 13kg)
- Accuracy Improvement: Periodic Error has been worked to be within ± 10 arc seconds – half that of the old version
- Low Temperature Tolerance: Ultra-Low temperature tolerance means you can operate as usual all the way down to -20°C (-4°F)
- Cable Management: DC Output and Type-C USB Port have been integrated into the dovetail plate to effectively prevent cable snagging/twisting
- New Bluetooth Function: a Bluetooth function can now be used to control the mount, which greatly improves the control experience.
Mount Body
The traditional equatorial mount requires heavy counterweights. It can be very difficult to keep balance in RA and DEC directions, also inconvenient for transit and storage, which bring the amateur astrophotographers a lot of pain when they are out for imaging.
Some of the strain wave geared drive mounts are relatively simple in functions, insufficient in load capacity, also not very stable in use.
The internal structure of the body optimized with the strain wave gear reducer and synchronous belt, bringing more accurate control and an amazing reduction ratio of 300:1.
Astronomy-Dedicated Strain Wave Gear
ZWO jointly developed the strain wave gearing system with well-known domestic manufacturers based on the actual needs of astrophotographers. It comes with very low periodic errors, smooth gearing and high torque. The guiding accuracy is 0.5-0.8 arc seconds, which makes the AM5N mount extremely suitable for astrophotography.
5.5kg Mount Weight, Large Load Capacity
While the portability is very important, the stability is also essential in use. We don't blindly pursue the lightweight of the mount body; we are more so along the lines of stability for entire use.
The capacity of this mount is 15kg without any counterweights attached, and increases to 20kg when using (up to) a 5kg counterweight.
Note: the counterweight should be secured on a counterweight bar of no more than 25cm in length.
Equatorial Mount / Altazimuth Mount
- Equatorial Mount Mode: Suitable for tracking and photographing objects
- Altazimuth Mount Mode: Suitable for observing objects
- You can switch between these two methods with the app, or through the hand controller.
Other Features
- Status Light Indicator
- Red Light: Indicated equatorial mount mode
- Green Light: Indicates altazimuth mount mode
- All-Round 0-90 Degree Pitch Angle
- Gear 1: Adjust the pitch angle grip to achieve any degree between 0 and 60
- Gear 2: Loosen the hex-head screw, then adjust the pitch angle grip to achieve any degree between 45 and 90
- Wireless Control
- Tonight's Target, GOTO, Live Preview, and so many great functions can be achieved through your phone, through either Wifi or Bluetooth connectivity
- Rocker-Style Hand Controller
- Comfortable touch and easy to use, integrated with WiFi network allows for wireless control, or connect with bluetooth
- Power Failure Protection
- ZWO AM5N mount is equipped with a brake design in case of a sudden power failure, which will prevent the telescope from falling and being damaged
- Seamless Linkage with ASAIR
- ASIAIR can control AM5N via wired or wireless connection. The ASI package gives customers the best astrophotography experience.
What's in the Box
Specifications
Mount type | Strain wave gear equatorial mount |
Mount mode | Equatorial mode / Altazimuth mode |
Drive | Strain wave gear + Synchronous belt (Reduction ratio: 300 : 1) |
Periodic error | <±10 arcseconds |
PE duration | 432 s |
Drive (RA) | NEMA42 stepper motor + Model No. 17 (Reduction ratio: 100:1) + Brake |
Drive (DEC) | NEMA35 stepper motor (Reduction ratio: 100:1) + Model No.17 |
Load capacity | 15kg without counterweight 20kg with counterweight |
Weight | 5.5kg |
Latitude adjustment range | Full 0°-90° |
Azimuth angle adjustment range | ±6° |
Dovetail | Losmandy & Vixen |
Interface thread of counterweight shaft | M12x1.75 |
Stepper motor resolution | 0.17" |
Max slew speed | 6°/s |
Slew rate | 0.5x, 1x, 2x, 4x, 8x, 20x,60x, 720x, 1440x |
Power port | DC5.5-2.1 (12V-3A) |
Power consumption | 12V / 0.386A (Standby) 12V / 0.58A (Tracking) 12V / 1.2A (GOTO) |
Guide port | ST4 |
Communication interface | USB/WiFi/Bluetooth |
Zero position | Mechanical |
Operating temperature | -20°C - 40°C |
Power failure protection | Yes |
